Signage & Retail Branding

Custom Signage Solutions & Retail Branding Experts

VVT Communications creates powerful brand identity signage that transforms spaces and captivates audiences. Our custom signage solutions include premium pylons, wayfinders, banners, and high-impact LED signage for unbeatable visibility. As top retail signage manufacturers, we deliver durable, innovative designs—ideal for stores, malls, and corporate branding—to amplify your brand presence and drive footfall.

Parameters/ Model	Pixel Pitch	Pixel Pitch	Pixel Pitch	Pixel Pitch
Pixel Pitch	2.0mm	2.5mm	3.0mm	4.0mm
Brightness	800cd/m2	800cd/m2	800cd/m2	800cd/m2
Colour Temperature	2000K-9300K Adjustable	2000K-9300K Adjustable	2000K-9300K Adjustable	2000K-9300K Adjustable
Cabinet Material	MS Cabinet	MS Cabinet	MS Cabinet	MS Cabinet
Viewing Angle	160°/ 140°	160°/ 140°	160°/ 140°	160°/ 140°
Maintenance	Front/ Rear	Front/ Rear	Front/ Rear	Front/ Rear
Refresh Rate	1920Hz	1920Hz	1920Hz	1920Hz
Operating Temperature/ Humidity	-20°C to 40°C/ 10%-80%RH	-20°C to 40°C/ 10%-80%RH	-20°C to 40°C/ 10%-80%RH	-20°C to 40°C/ 10%-80%RH
Storage Temperature/ Humidity	-20°C to 55°C/ 10%-65%RH	-20°C to 55°C/ 10%-65%RH	-20°C to 55°C/ 10%-65%RH	-20°C to 55°C/ 10%-65%RH

Parameters/ Model	Pixel Pitch	Pixel Pitch	Pixel Pitch	Pixel Pitch	Pixel Pitch	Pixel Pitch
Pixel Pitch	2.5mm	3.0mm	4.0mm	6.0mm	8.0mm	10.0mm
Brightness	5500cd/m2	5500cd/m2	5500cd/m2	5500cd/m2	5500cd/m2	5500cd/m2
Colour Temperature	2000K-9300K Adjustable	2000K-9300K Adjustable	2000K-9300K Adjustable	2000K-9300K Adjustable	2000K-9300K Adjustable	2000K-9300K Adjustable
Cabinet Material	MS Cabinet	MS Cabinet	MS Cabinet	MS Cabinet	MS Cabinet	MS Cabinet
Viewing Angle	140°/ 140°	140°/ 140°	140°/ 140°	140°/ 140°	140°/ 140°	140°/ 140°
Maintenance	Rear /Front	Rear /Front	Rear /Front	Rear /Front	Rear /Front	Rear /Front
Contrast Ratio	≥3500:1	≥3500:1	≥3500:1	≥3500:1	≥3500:1	≥3500:1
Refresh Rate	1920Hz	1920Hz	1920Hz	1920Hz	1920Hz	1920Hz
Operating Temperature/ Humidity	-10°C to 50°C/ 10%-80%RH	-10°C to 50°C/ 10%-80%RH	-10°C to 50°C/ 10%-80%RH	-10°C to 50°C/ 10%-80%RH	-10°C to 50°C/ 10%-80%RH	-10°C to 50°C/ 10%-80%RH
Storage Temperature/ Humidity	-10°C to 50°C/ 10%-80%RH	-10°C to 50°C/ 10%-80%RH	-10°C to 50°C/ 10%-80%RH	-10°C to 50°C/ 10%-80%RH	-10°C to 50°C/ 10%-80%RH	-10°C to 50°C/ 10%-80%RH

Screen Size (Diagonal)	(21.5″,24″,32″,43″,55″,65″)
Aspect Ratio	16:09
Contrast	1200:01:00
Display Color	16.7M
Response Time	8ms
Android	11.0
CPU	Quad core ARM Cortex-A35
GPU	ARM G31 MP2
Ram	4GB
Storage	32GB
Interface	HDMI IN 1, USB2, RJ45*1
Speaker	2 × 10W (8 Ω )
Touch Technology	Capacitive Multi Touch
Click Manner	10 Points
Power Supply	AC 100~240V 50/60Hz
Operation Temperature	0°C~40°C
Color	As per requarment
Body Dimension w/o Stand	Customized
Native Resolution	1920 x 1080
Brightness	350 cd/m2
View Angle	178°(H)/178°(V)
Operation Duration	167 / 247 Hours
Life Time (Light Source)	50,000 Hrs (Min.)
O/S	Android 9.0
Ram	4GB
Storage	32GB
Networks	LAN, WIFI,HDMI,USB
Response Time	≤ 6ms
Power Consumption	≤ 85W
Operation Humidity	20%~80% RH
Tempered Glass	Yes

Screen Size (Diagonal)	(32″,43″,49″,55″,65″)
Aspect Ratio	16:09
Contrast	19-02-1900 00:01
Display Color	16.7M
Response Time	8ms
CPU	Quad core ARM Cortex-A35
Ram	2GB
Storage	8GB
Interface	HDMI IN 1, USB2, RJ45*1
Speaker	2 × 10W (8Ω)
Power Supply	AC 100~240V 50/60Hz
Operation Temperature	0°C~40°C
Color	As per requarment
Body Dimension w/o Stand	Customized
Native Resolution	1920 × 1080
Brightness	350 cd/m²
View Angle	178°(H) / 178°(V)
Operation Duration	167 / 247 Hours
Life Time (Light Source)	50,000 Hrs (Min.)
O/S	Android 11.0
Ram	2GB
Storage	16GB
Networks	LAN, WIFI,USB,HDMI,REMOTE
Power Consumption	≤ 85W
Operation Humidity	20%~80% RH
Tempered Glass	Yes

Pixel Pitch	6mm – 20mm
Display Thickness	3 mm
Brightness	5000 nits
Transparency Rate	80% – 95%
LED Chip	SMD2020
Product Size	960230mm/1200230mm/1500*230mm
Power Consumption	Average: 240W/m², Maximum: 800W/m²
Screen Weight	≤2kg/m²
Power Supply Brand	YUANCHI
Transparency Rate	>80%-95%
IP Rating	IP45
Average Lifespan	≥100,000 operating hours
Power Requirements	110-220V±10%; AC50/60HZ
Screen Brightness	1500-5000cd/m²
Viewing Distance	6m-250m
Viewing Angle	Horizontal ≥160° Vertical ≥140°
Gray Level	≥16 bit
Color Temperature	5500K-15000K (adjustable)
Driving Method	Static
Attenuation Rate	Less than 0.05% in 2 years
Refresh Rate	≥3840HZ
Frame Rate	≥60HZ
Trouble-Free Operating Time	≥10,000 hours
Led Chip Failure Rate	≤1/10,000
Control System	Colorlight/Novastar
Operating Environment	-10~+65°C
Installation Method	Adhering to glass, Hanging installation, fixed installation. Support arbitrary size cropping and bending

Signage & Retail Branding

Custom Signage Solutions & Retail Branding Experts

Work Gallery

We would like to
hear from you

Pixel Pitch	0.8 mm
LED Type	Black SMD1010
Panel Dimensions (WHD) (mm)	As per requirement.
Panel Weight (kg)	As per requirement.
Module Size (W*H)	320×160
Refresh Rate (Hz)	1920~3840
Contrast Ratio	4000:01:00
Viewing Angle (H/V) (°)	140/140
Viewing Distance	0.8 meter
Panel Resolution	512×384
Panel Material	As per requirement.
Brightness (nit)	600
Grayscale (bit)	13~14
Color Temperature (K)	6500
Installation options:	Stacking, mounting, hanging

Pixel Pitch	4mm
LED Type	Black SMD1010
Panel Dimensions (WHD) (mm)	As per requirement.
Panel Weight (kg)	As per requirement.
Module Size (W*H)	320×160
Refresh Rate (Hz)	3840
Grayscale (bit)	16
Power Consumption	630/210
Panel Resolution	288×216
Panel Material	As per requirement.
Ingress Protection	IP65/IP54
Viewing Angle (H/V) (°)	160/160
Viewing Distance	4 meter
Brightness (nit)	5000
Installation options:	As per requirement.
